VS-VB28D-F
2MP AI IR Bullet Camera (NEW!)
- 1/2.8″ 2MP CMOS Sensor
- Low-Light Performance down to 0.004 Lux
- Motorized 2.8-12mm Lens with 97°~32.2° Viewing Angle
- Advanced WDR, HLC, and Defog Image Enhancement
- 30m IR Distance for Effective Night Surveillance
- Up to 2MP (1920 x 1080) Resolution at 25fps
- Supports H.265+, H.265, H.264+, H.264, MJPEG
- 256GB Built-in Storage Capacity
- ONVIF and CGI Compatibility
- People Counting, Facial Recognition, Heatmap (optional)
- Event Detection: Motion, Intrusion, Line Crossing, Loitering, Abandoned Items, Object Loss, Unauthorized Access
- Smart Monitoring: Entry/Exit Zone
Specification
| Model | VS-VB80B-F | VS-VB28D-F |
| Imaging Sensor | 1/2.8’’;8MP;CMOS | 1/2.8’’;2MP;CMOS |
| Mini. illumination Color: 0.003 Lux (F1.6, AGC on), 0 Lux with IR | Mini. illumination Color: 0.004 Lux (F1.3, AGC on), 0 Lux with IR | |
| Image Enhancement | WDR, HLC, Defog | WDR, HLC, Defog |
| Lens | Focus: 2.8mm(4mm;3.6mm;6mm) | Motorized : 2.8-12mm |
| Viewing Angle: 106.5 ° | Viewing Angle: 97°~32.2° | |
| Aperture: Fixed | Aperture: Fixed | |
| Max IR Distance | 30m | 30m |
| Video and Encoding | Maximum Resolution: 8MP (3840 × 2160) | Maximum Resolution: 2MP (1920 x 1080) |
| H.265+, H.265, H.264+, H.264, MJPEG | Frame Rate: 25fps@2mp | |
| Frame Rate: 25fps@4mp | H.265+, H.265, H.264+, H.264, MJPEG | |
| ROI: 4 | ROI: 4 | |
| Corridor Mode: Optional | Corridor Mode: Optional | |
| Multiple Streams: 3 streams | Multiple Streams: 3 streams+ |
| Audio and Alarm | Audio I/O: 1-channel audio interface MIC IN/Line IN | Audio I/O: 1-channel audio interface MIC IN/Line IN |
| Alarm I/O: 1-channel audio interface (line level,600Ω) | Alarm I/O: 1-channel audio interface (line level,600Ω) | |
| Storage Capacity | Storage Capacity: 256G | Storage Capacity: 256G |
| Compatibility | ONVIF , CGI | ONVIF , CGI |
| Intelligent + | •People Counting•facial recognition•Heat map•Entry Zone & Exit Zone•Motion Detection• Unauthorized Intrusion• Line Crossing Detection•Loitering Detection• Abandoned Items• Object Loss• Unauthorized Access | •People Counting•facial recognition•Heat map•Entry Zone & Exit Zone•Motion Detection• Unauthorized Intrusion• Line Crossing Detection•Loitering Detection• Abandoned Items• Object Loss• Unauthorized Access |
| Network and Power | Network Connectivity: 10M/100M Base-TX Ethernet | Network Connectivity: 10M/100M Base-TX Ethernet |
| Power Supply: DC 12V; POE(802.3af)(Optional) | Power Supply: DC 12V; POE(802.3af)(Optional) | |
| Environmental Details | Environmental Ruggedness: 40°F to 140°F (-40°C to 60°C) | Environmental Ruggedness: 40°F to 140°F (-40°C to 60°C) |
| IP Rating: IP 67 | IP Rating: IP 67 | |
| Other available models : | 2MP:VS-VB28B-F | 5MP:VS-VB59G-F(3.6-11) |
| 4MP:VS-VB47B-F | 8MP:VS-VB80S-F(5-50) | |
| 5MP:VS-VB80B-F |
